CHA SERVO DS06 HV (1,8KG / 0,07S, @ 8,4V)
€32.90
Op voorraad (kan nabesteld worden)
Omschrijving
- Dimensions : 20 mm x 7.4 mm x 18.7 mm
- Weight : 6.1 g
- Rated Voltage : DC 7.4 V
- Voltage Range : DC 3.3 – 9.0 V
- Torque : 0.8 kg.cm @ 3.5V || 1.5 kg.cm @ 6.0V || 1.8 kg.cm @ 8.4V
- Speed : 0.12 sec/60° @ 3.5V || 0.08 sec/60° @ 6.0V || 0.07 sec/60° @ 8.4V
- Max. Current : 0.30 A @ 3.5 V || 0.58 A @ 6.0 V || 0.67 A @ 8.4 V
- Case Material : High Quality Technopolymer
- Gear Set Material : Hardened Steel + Plastic
- Ball Bearing : 2x Ball Bearing
- Position Sensor : Potentiometer
- Motor Type : Hollow Cup DC Motor
- Working Frequency : 1520 µs / 20 KHz
- Pulse Range : 900 µs – 2100 µs
- Programmable : Yes
- Gear teeth : 15T
Aanvullende informatie
| Gewicht | 0.1 kg |
|---|---|
| Afmetingen | 10 × 5 × 5 cm |
