DESCRIPTION
Although relatively new in the game, CHAservo has conquered its place within the RC market of servos and is still growing.
Trusted by many of the best RC-pilots worldwide, CHAservo offers ‘championship performance’ with their innovative servo’s. Proven by great specs yet at fairly competitive prices, making it one of the preferred servo brands of the Aerobertics Team, available at our webshop.
- Dimensions 23 x 11.5 x 24.5 mm
- Weight 15 g
- Rated voltage DC 7.4V
- Voltage range DC 4.0 – 9.0V
- Holding Torque @ 3.5V 3.6 kg-cm / @ 6.0V 5.5 kg-cm / @ 8.4V 6.0 kg-cm
- Speed: 0.13sec/60° @ 4.8 V / 0.09sec/60° @ 7.4 V / 0.08sec/60° @ 8.4 V
- Toothing 25T, 5 mm
- Position sensor Potentiometer
- Motor Coreless DC
- Ball Bearing 2 x Ball Bearing
- Operating frequency 1520µs / 333Hz
- Pulse width 900µs – 2100µs
- Programmable Yes
- Metal Gear
